BIM objektumok - Ingyenes letöltés! P1 Player One Sports Light

CONSTRUCTION
- Cold Weather Starting: Minimum starting temperature is -40°C (-40°F)
- Maximum Ambient Temperature: Suitable for use in up to 50°C (122°F)
- Housing: Precision die-cast aluminum
- Mounting:
  - Standard Yoke Mount.
  - Drivers can be mounted on the fixture bracket on top of the cross arms or remotely on the poles using driver mounting bracket accessories.
  - Slipfitter mount, square beam mount and rail mounting kits sold separately.
- Tilt Increment: Continuous tilting with 5 degree increments
- Lens: Polycarbonate
- Gasket: Silicone
- Green Technology: Mercury and UV free. RoHs-compliant components.
- Finish: Formulated for high durability and long lasting color
- NEMA: NEMA beam spread of 2HX2V, 3HX3V & 4HX4V
- IP Rating: Ingress protection rating of IP65 for dust and water
- EPA
TECHNICAL SPECIFICATIONS
- PERFORMANCE
  - MODEL 0° 15° 25° 45° 60° 75° 90°
    - P1S 1.29 1.29 1.43 1.71 1.87 2.0 2.10
    - P1M 1.29 1.29 1.43 1.71 1.87 2.0 2.10
    - P1L 1.67 1.75 1.89 2.25 2.48 2.66 2.77
    - P1XL 1.67 1.75 1.89 2.25 2.48 2.66 2.77
    - P1RGB 1.29 1.29 1.43 1.70 1.87 2.0 2.07
LED CHARACTERISTIC
- LEDS: Long-life, high-efficacy, surface-mount LEDs
- Color Uniformity: RAB's range of Correlated Color Temperature follows the guidelines of the American National Standards for Specifications for the Chromaticity of Solid State Lighting (SLL) Products, ANSI C78.377-2017.
COMPLIANCE
- UL Listed: Suitable for wet locations
- DLC Listed: This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
- Model# Product ID Model# Product ID
  - P1S S-9DCGGH P1S/480 S-F7B6ZQ
  - P1S 2HX2V S-PL8YHP P1S/480 2HX2V S-2FTHKL
  - P1S 3HX3V S-T8W5F5 P1S/480 3HX3V S-0HPWPH
  - P1M S-51FM2M P1M/480 S-ZWXHP5
  - P1M 2HX2V S-J1SR7K P1M/480 2HX2V S-KWBDB1
  - P1M 3HX3V S-K2CRW3 P1M/480 3HX3V S-H3LFFS
  - P1L S-PCL0MK P1L/480 S-Y6191J
  - P1L 2HX2V S-PXGSD9 P1L/480 2HX2V S-TFMDCP
  - P1L 3HX3V S-65507D P1L/480 3HX3V S-YGB35J
  - P1XL/480 S-X4VKFB
  - P1XL/480 2HX2V S-ZW7SC9
  - P1XL/480 3HX3V S-SF1WMX
ELECTRICAL
- Drivers: Constant Current, Class 1, 120-277V, 50/60 Hz
  - P1S: 120V: 4.31A 208V: 2.48A, 240V: 2.15A, 277V: 1.86A
  - P1M: 120V: 5.20A 208V: 3.01A, 240V: 2.61A, 277V: 2.29A
  - P1L: 120V: 6.96A 208V: 4.00A, 240V: 3.45A, 277V: 3.01A
  - P1RGB: 120V: 4.28A 208V: 2.46A, 240V: 2.12A, 277V: 1.84A
- Drivers: Constant Current, Class 1, 200-480V, 50/60 Hz
  - P1S/480: 208V: 2.54A 240V: 2.19A, 277V: 1.89A, 480V: 1.09A
  - P1M/480: 208V: 3.01A 240V: 2.61A, 277V: 2.26A, 480V: 1.31A
  - P1L/480: 208V: 4.18A 240V: 3.63A, 277V: 3.15A, 480V: 1.86A
  - P1XL/480: 208V: 6.15A 240V: 5.33A, 277V: 4.61A, 480V: 2.65A
  - P1RGB: 208V: 2.45A 240V: 2.12A, 277V: 1.84A, 480V: 1.05A
- Dimming Driver: Driver includes wiring for 0-10V dimming systems. Dim as low as 10%.
- Surge Protection: 120-277V: 10kV and 200-480V: 20kV
